Description
XTensa dual-core 32-bit LX7 CPU, frequency up to 240MHz
2.4 GHz Wi-Fi, EEE 802.11 b/g/n-compliant
Bluetooth, LE: Bluetooth 5, Bluetooth mesh
16 MB (64Mbit) SPI Flash
384 KB ROM
512 KB SRAM
8 MB SPI PSRAM
16 KB SRAM in RTC
Communication Interfaces
2 x I2C
2 x I2S
4 x SPI
3 x UART
1 x USB OTG
Security
4096 bit OTP
AES, SHA, RSA, ECC and RNG
Secure boot, Flash encryption, Digital signature, HMAC module
Dual Type-C USB connectors
Reset and User/Firmware buttons
RGB WS2812 User LED
Power LED
Virtual USB port provided by CP2102 for debugging and firmware upgrade
Supply Voltage: 5V via USB
Circuit Voltage: 3.0 to 3.6V Circuit Operation
Dimensions: 50.1 x 13mm
Features:
Low-Power MCU: The XTVTX ESP32 S3 core board, based on WROOM-1-N16R8, is a low-power MCU, making it suitable for applications that require extended battery life.
Support for Multiple Low-Power Modes: This ESP32-S3 development board supports various low-power modes, making it an excellent choice for IoT and mobile device applications.
Arduino IDE Compatibility: It seamlessly integrates with Arduino IDE, simplifying the programming process. You can quickly develop a wide range of DIY projects.
Versatile Applications: ESP32-DevKitC-1 Suitable for a wide range of DIY projects, including smart home automation, IoT devices, and robotics. It can handle whatever your project demands.
